Exchange AD Split Permissions without regrets

TLDR: what if we remove the downsides?

I found a way to re-grant AD and RBAC permissions directly where Exchange users, groups, and contacts reside, requiring no changes for admins or identity management systems. In my experience, that friction has been the primary blocker for most companies. And we still retain the security benefits against lateral movement and domain compromise.

It’s achieved in three steps:

1. Implement AD split permission model
2. Grant Exchange servers the lost AD permissions, but only on the relevant OUs
3. Grant Exchange RBAC to re-enable missing PowerShell cmdlets

All via Microsoft’s guidance, AD ACLs or Exchange RBAC assignments.

Why do we care (now)?

It has been largely overlooked or ignored since it was introduced with Exchange 2010 SP1. But the default shared permissions model represents a big security risk of Active Directory takeover. Combined with Exchange being notorious for remote exploits the last few years, it’s time to act!

The problem originates from privileges granted to the root of a domain that get inherited throughout the domain.

• modify permissions on users and groups (effectively full access)
• modify group members
• reset password on users
• create/delete users and groups

Only certain highly privileged Tier 0 users and groups are protected by the AdminSDHolder process (attribute admincount=1) and in many environments there will be unprotected users or groups that could allow compromise of the domain and/or forest or at least cause serious impact.

Prominent examples:

• Entra Connect Sync account when using Password Hash Sync
• Default groups
  • Allowed RODC Password Replication Group together with Entra Connect account (if a real Windows RODC exists)
  • Also see Untrustworthy Trust Builders: Account Operators Replicating Trust Attack (AORTA) - SpecterOps showing more paths (Account Operators group is a similar threat)
  • Emptying Protected Users to create attack vectors by removing protections
• Unprotected custom groups or admin/service accounts
  • Write permission on GPOs (applying to domain controller)
  • Managing access to AD backups, backup server, PKI templates, hypervisor, ...

It is very hard to retroactively contain all these current and future potential pathways. For the _ADM custom OU, you could disable ACL inheritance, but most default objects may not be moved from the default Builtin OU or Users container and remain vulnerable.

It is much better to remove the powerful permissions from the root, which is done by implementing the Active Directory split permissions model. Configure Exchange Server for split permissions | Microsoft Learn

And Microsoft agrees “…encouraged to implement Active Directory split permissions” Active Directory Hardening Series - Part 7 – Implementing Least Privilege | Microsoft Community Hub

But why is no one doing it?

As split permissions weren’t available until Exchange 2010 SP1, everyone had accepted it by then and it seems that security teams did not manage to push it successfully once it existed.

And it would have forced changes to admin and IDM processes, like creating users or distribution lists in AD first and only afterwards using Exchange to “mail enable” them.

Info: The following cmdlets will no longer be available or working: Add-DistributionGroupMember, New-DistributionGroup, New-Mailbox, New-MailContact, New-MailUser, New-RemoteMailbox, Remove-DistributionGroup, Remove-DistributionGroupMember, Remove-Mailbox, Remove-MailContact, Remove-MailUser, Remove-RemoteMailbox, Update-DistributionGroupMember, Add-ADPermission, Remove-ADPermission

Adoption examples:

• New-Mailbox (where Exchange writes to AD) would be:
  • New-ADUser (where adm.jdoe writes to AD)
  • Enable-Mailbox
• Add-ADPermission for SendAs rights would have to be done via AD users and computers in the security tab and often requiring additional AD permissions for standard admins.

Show me this no-regrets option!

Disclaimer: Please fully read and understand the following links and articles, perform it in a test environment first, make sure AD backups are current and recovery practices are established!

Audit current usage

You should first check which of the affected cmdlets are in use on which OUs:

Quick Analysis of caller and cmdlets:

Analyze the CSV for where AD permissions will be needed. Potentially optimize by moving all Exchange-relevant groups into dedicated OUs.

Enable Split Permissions Model

Follow Microsoft's instructions "Switch to Active Directory split permissions" in Configure Exchange Server for split permissions | Microsoft Learn(NOT RBAC split permissions)

In essence, it will remove the dangerous permissions of the "Exchange Windows Permissions" group and also remove Exchange as a group member.

Grant AD Permissions

Create a custom AD group and make Exchange servers members.

I’ve created a script to make delegating the AD permissions easy per use case.

Without these permissions the Exchange server would receive the error “INSUFF_ACCESS_RIGHTS” from AD.

Download Add-ExchangeADSplitPermissionOnOU.ps1 from glueckkanja GitHub

It can grant the following PermissionTypes:

CreateUserAndContact
Create/delete, ResetPassword and WriteAllProperties for Users and Contacts
Exchange cmdlets: `New-Mailbox`, `New-RemoteMailbox`, `New-MailUser`, `New-MailContact` and matching `Remove-*`

GroupManage
Create/Delete Groups, Modify Member
Exchange cmdlets: `New-DistributionGroup`, `Remove-DistributionGroup`, `Add-DistributionGroupMember`, `Update-DistributionGroupMember`, `Remove-DistributionGroupMember`
Also: user managing DistributionGroups they own via EAC

UserSendAs
Modify AD Permissions on Users
Exchange cmdlet: `Add-ADPermission`

GroupSendAs
Modify AD Permissions on Groups
Exchange cmdlet: `Add-ADPermission`

How to use the script:

Grant Exchange RBAC

Re-enable -BypassSecurityGroupManagerCheck parameter for Add-DistributionGroupMember and Remove-DistributionGroupMember cmdlets:

Info: Else you get "-BypassSecurityGroupManagerCheck parameter is not available" or "You don't have sufficient permissions. This operation can only be performed by a manager of the group"

Re-enable New-Mailbox, New-RemoteMailbox, New-MailContact, Remove-... cmdlets with needed parameters:

Conclusions

I hope this guide helps more organizations take the important step of securing their Active Directory against compromise via Exchange. In my experience implementing the Exchange AD Split Permissions model across multiple customers, I have not encountered any issues and the adoption has been smooth.

I also hope Microsoft will introduce a native, OU-based approach to achieve this level of granularity, rather than the current all-or-nothing model, which would make widespread adoption significantly easier.

A note on AD Tiering: Please do not log on to Exchange servers with Domain Admin or any other Tier 0 accounts. Treat Exchange servers as Tier 1 and implement AD Tiering as soon as possible. As a first step, I recommend using PingCastle or Purple Knight to assess your AD security posture and identify control path exposures.
